Description
HEAVY DUTY GALVANISED METAL TT type FENCE POST ANCHORS SUPPORT
| Description |
| TYPE ONE : (LEFT SIDE OF THE PICTURE)
thickness 5mm 2 x 2 ( 8mm side holes ) 2 x 2 ( 8mm base holes ) recommended screws 8mm recommended fixings M8 full length welds
sizes and dimensions: 60mm (2.36″) : height 150mm base 520mm x 150mm 75mm (3″) : height 150mm base 60mm x 160mm 80mm : height 150mm 150mm (5.9″) : height 200mm base 100mm x 300mm 200mm (7.9″) : height 200mm base 100mm x 300mm |
TYPE TWO : (RIGHT SIDE OF THE PICTURE)
2 x 2 ( 8mm ) base holes
2 x 2 (8mm ) side holes
2 x 4 (8mm ) side holes
Height 200mm
Thickness 5mm
Recommended fixings m8 or m6
recommended screws 6mm or 8mm
bearing capacity : steel 117.5kN
wood 31.9kN
70mm (2.8″) : base 60mm x 160mm
90mm (3.5″) : base 60mm x 180mm
100mm (4″) : base 60mm x 190mm
120mm (4.8”) : base 60mm x 210mm
140mm (5.5”) : base 60mm x 230mm
150mm (5.9”) : base 60mm x 230mm
200mm (7.9”) : base 60mm x 280mm
This kind of post support is often used where there`s a strict requirement for hiding the support to maintain the aesthetic.
The feature of the T-T shape bracket is to prevent the contact between the post and the ground.
SET OF CONNECTORS/DOWELS AVAILABLE HERE :
https://www.adnacomponents.co.uk/product/set-of-dowels-connectors-100mm-150mm-200mm/
Please note that occasionally the colour of the galvanised finish may vary from the one on the picture.
